250VAC 150A Inverter EMI Filter RFI Suppression Filter For VFD

Name: 250VAC 150A Inverter EMI Filter RFI Suppression Filter For VFD
Brand: VIIP
Price: 1 USD

Brand Name : VIIP

Model Number : VIP6-33M-150

Certification : CE TUV UL ROHS REACH

Place of Origin : China

MOQ : Negotiable

Price : Negotiable

Payment Terms : T/T, Western Union

Supply Ability : 2000 pcs within 10-15 days

Packaging Details : 33*33*18

Rated voltage : 110/250VAC

Rated current : 150A

Nominal center frequency : 50/60Hz

MOQ : 1 PCS

Application : VFD Inverter

Line to line : 2700VDC

Contact Now

150A Inverter EMI Filter Emi Suppression Filters For VFD Inverter Three Phase Inverter

Description:

1, Rated currents from 0.5 to 2000A

2, High attenuation performance up to 30 MHz

3, Voltage rating 440VAC for worldwide acceptance

4, Approvals: CE, ROHS

Specification:

Item	3 Phase EMI Filter
Model	3 Phase EMI Filter - VIP6 Series
Transfer Function	Low Pass
Package Type	Surface Mount
Nominal working Frequency	150K-30MHZ
Insertion Loss	60~90dB
Input Impedance	50Ω
Rated Voltage	380V/440V
Current	150A
Working Temperature	40°C
Temperature	25 / 085 / 21
Operating Frequency	50/60HZ
Line to Line	2250VDC
Line to Ground	2700VDC
	110VAC/60HZ 1.4mA
MOQ	5pcs
Port	Shenzhen
Leading Time	3~15 weekday for Low Pass EMI Filter

Specifications:

250VAC 150A Inverter EMI Filter RFI Suppression Filter For VFD

Applications:

1. Mainframe computer systems

2. Servo motor

3. UPS/SMPS

4. Industrial electronic equipment by using frequency conversion principle
